Features:
- Sensor/ detection principle: Photoelectric proximity sensor, Background suppression
- Dimensions (W x H x D): 27 mm x 87.5 mm x 65 mm
- Housing design: Rectangular
- Sensing range max: 100 mm … 2,500 mm
- Sensing range: 100 mm … 2,500 mm
- Light source: LED
- Type of light: Infrared light
- Light spot size (distance): Ø 80 mm (2,500 mm)
- Housing material: Metal, zinc diecast /Plastic PMMA
- Enclosure rating: IP 67
- Adjustment: Potentiometer
Mechanics/ Electronics:
- Power supply: 10 V DC … 30 V DC
- Switching output: NPN/PNP – Light/Dark switching
- Switching frequency: 1,000 Hz
- Response time: ≤ 500 µs
- Connection type: Male connector M12, 4-pin
- Temperature range: –40 °C … +60 °C
