The RFH630-1102101 SICK is RFID, reading range ≤ 240 mm, radio approval global, frequency band HF (13.56 MHz), RFID standard ISO/IEC 15693, ISO/IEC 18000-3 “Mode 1”, connection type ethernet.

The RFH620-1001201 SICK is RFID, reading range ≤ 150 mm, radio approval global, frequency band HF (13.56 MHz), RFID standard ISO/IEC 15693, ISO/IEC 18000-3 “Mode 1”, connection type ethernet

The RFH620-1001201 SICK is RFID, reading range ≤ 150 mm, radio approval global, frequency band HF (13.56 MHz), RFID standard ISO/IEC 15693, ISO/IEC 18000-3 “Mode 1”, connection type male connector

• Optimally aligned antenna characteristics prevent faulty readings, therefore ensuring high process stability
• Reliable operation thanks to rugged design - even under rough industrial environments
• Rugged design in accordance with enclosure rating IP67
• Ambient temperature ranges from −40 °C to +70 °C
• Integrated feedback LEDs

• Quick and low-cost installation thanks to direct connection option for trigger sensors
• Simple connection with M12 cable for IO-Link variants
• Configuration via SOPAS ET
• Ethernet-based variants: Compatible with SICK AppSpace
• Rugged design (IP67)

• Product category: RFID read/write device with integrated antenna
• Frequency band: HF (13.56 MHz)
• Read range: ≤ 35 mm ... ≤ 80 mm
• Reading and writing of transponders in accordance with ISO/IEC 15693
• IO-Link interface: COM3 data transmission rate (230.4 kBaud), process data size 32 bytes

• Product category: RFID read/write device with integrated antenna
• Frequency band: HF (13.56 MHz)
• Read range: ≤ 150 mm / ≤ 240 mm
• Transponder communication according to ISO/IEC 15693 standard
• Embedded protocols allow interfacing with standard industrial fieldbus technologies
• Supports parameter cloning via microSD memory card

• Low price and maintenance-free.
• Standard-compatible transponders enable future-proof solutions.
• Mounting on various materials possible, even on metallic surfaces.
• Ambient temperature range from −40 °C to +230 °C.
