Kiln shell line scanner Centurion TK50 Thermoteknix
Centurion TK50 Thermoteknix is Kiln shell line scanner; Scanning rate: 30Hz; Linear samples per scan: 2048; Scanning field of view: 120°; Temperature range: 60-700°C
Camera ThermaScope HDT Thermoteknix
Camera ThermaScope HDT Thermoteknix; Temperature range: 600 to 1800’C; CCD format: 1280 x 960; Dynamic range: >115db; Frame rate: 60Hz
Camera ThermaScope HDC Thermoteknix
Camera ThermaScope HDC Thermoteknix; CCD format: 1280 x 960; Display Output: 1280 x 720p (HD) Progressive Scan; Dynamic range: >115db; Response Time: 60Hz
ThermaScope Multiview Thermoteknix
ThermaScope Multiview Thermoteknix; Record, replay and analyse ThermaScope HD footage; Fully interactive timeline; Linked kiln and cooler views; Full OPC compliance
Multiview enterprise Thermoteknix
Multiview enterprise Thermoteknix; Measure & analyse retrospectively; Advanced real-time monitoring; Real-time alarming
Temperature sensors TBS-1BSGT1506NM SICK –20 °C to +80 °C
Insertion length/diameter of probe: 150 mm / 6 mm; Measuring range: –20 °C ... +80 °C; Power supply: 15 V DC ... 35 V DC; Switching output: 1 x PNP + 4 mA ... 20 mA
Temperature sensors TBS
- Measuring ranges –20 °C ... +120 °C
- Pt1000 element, accuracy class A (IEC 60751)
- Accuracy of sensor element: ≤ ± (0.15 °C + 0.002 |t|)
- Very reliable: splash-proof housing, high-grade materials, rugged design, and field-proven technology
- Individually programmable transistor outputs PNP or NPN, optional analog output 4 mA ... 20 mA or 0 V ... 10 V
Temperature sensors TBT
- Well-proven temperature measurement
- Measuring range: –50 °C +150 °C/ –50 °C +250 °C
- Accuracy of sensor element: Class A according to IEC 60751
- Accuracy of the opt. measuring transducer: ≤ ± 0.1 % of span
- Signal outputs and maximum ohmic load RA: Pt100, 4-wire, 4 mA ... 20 mA, 2-wire (RA ≤ (L+ – 10 V) / 0.028 A [Ohm])
- Electrical connection: Cable gland M16 x 1.5, IP65/ Cable gland M16 x 1.5, IP67
2-wire transmitter APAQ C130TC INOR
APAQ C130TC INOR is Digital 2-wire transmitter for thermocouple; Type: Head mounted; Input: Thermocouple B, E, J, K, N, R, S and T; Output: 4-20 mA; Wireless communication: NFC®
2-wire transmitter APAQ C130RTD INOR
APAQ C130RTD INOR is Digital 2-wire transmitter for Pt100 and Pt1000; Type: Head mounted; Input: Pt100 and Pt1000; Output: 4-20 mA; Wireless communication: NFC®
2-wire transmitter APAQ R130TC INOR
APAQ R130TC INOR is digital 2-wire transmitter for thermocouple; Type: Rail mounted; Input: Thermocouple B, E, J, K, N, R, S and T; Output: 4-20 mA; Wireless communication: NFC®
2-wire transmitter APAQ R130RTD INOR
APAQ R130RTD INOR is digital 2-wire transmitter for Pt100 and Pt1000; Type: Rail mounted; Input: Pt100, Pt1000; Output: 4-20 mA; Wireless communication: NFC®
2-wire transmitter IPAQ C330 INOR
IPAQ C330 INOR is Universal 2-wire transmitter with wireless communication; Type: Head-mounted; Input: RTD, TC, mV, ohm; Output: 4-20 mA; Wireless communication: NFC® and Bluetooth®
2-wire transmitter IPAQ C202 INOR
IPAQ C202 INOR is 2-wire transmitter; Type: Head mounted; Input: RTD; Type of transmitter: Digital; Output: 4-20 mA; Isolation: Unisolated; Measuring channels: 1 channel; Sensor connection: 3-wire connection
2-wire transmitter IPAQ R330 INOR
IPAQ R330 INOR is Universal 2-wire transmitter with wireless communication; Type: Rail-mounted; Input: RTD, TC, mV, ohm; Output: 4-20 mA; Wireless communication: NFC® and Bluetooth®
2-wire transmitter IPAQ C310RTD INOR
IPAQ C310RTD INOR is Programmable 2-wire transmitter for RTD and Resistance inputs; Type: Head-mounted; Input: RTD, ohm, RTD: Pt100, Pt10 … Pt1000, Ni100, Ni120, Ni1000; Output: 4-20 mA; Wireless communication: NFC and Bluetooth®
