Rotary Encoders
TTK70 Linear Encoder SICK | AUMI
- Measuring length: up to 4 m.
- Maintenance-free and wear-free operation thanks to the non-contact sensing principle
- No reference travel required, as absolute position is recorded
- High travel speed of up to 10 m/s
- Reliable measurement even under contamination and condensation on the magnetic tape
Measuring Wheel Encoder MWS075 SICK Official | AUMI
- Compact measuring wheel system with low installation depth, saving valuable machine space
- Consistent spring-loaded contact force compensates for uneven surfaces
- Quick and easy installation for fast commissioning
- Flexible solution for linear measurement tasks with various wheel surfaces and adjustable contact pressure
- Mechanical travel limit protects the spring from overload and prevents system damage
- Highly customizable with multiple encoder types and interface options
Motor feedback systems Scon
- The compact design enables simple integration into the motor assembly area.
- Thanks to the external temperature input, additional temperature values can be transmitted via the HIPERFACE-DSL® protocol – additional cabling is not required
- Enclosure rating: IP00
- Input connector: Male connector, 8-pin
- Output connector: Male connector, 4-pin
Linear encoders STL/ETL70
- Simple integration of the system thanks to the HIPERFACE® or HIPERFACE DSL® interface
- STL70-2 certified according to SIL2 and PL d (HIPERFACE® interface)
- Measuring lengths: up to 16,384 mm
- High traversing speeds: up to 10 m/s
Incremental encoders DFS60S Pro
- Versatile connection options for high levels of flexibility and straightforward implementation
- Compact size for compatibility with applications in which installation space is limited
- Electrical interface: 4.5 V ... 32 V; sine/cosine 1 VPP; 1,024 periods
- Enclosure rating: IP65
- Operating temperature range: –30°C ... +95°C (depending on type)
Measuring wheel encoders MWS120
- Smart design for easy integration into the application and control environment
- Time-saving thanks to easy integration and quick commissionin
- Contact pressure can be adjusted manually from 0-24 N in 6 steps
- Compact axle spacing (120 mm) for flexible installation options
Linear encoders TTK70
- Measurement lengths of up to 4 m
- Maintenance and wear-free thanks to non-contact measurement principle
- No need for a reference run due to the absolute position recording
- For high traversing speeds of up to 10 m/s
- Reliable measurements, even in the event of contamination and condensation on the magnetic tape
Linear encoders MAX
- 100% mechanical and electrically compatible with existing cylinder constructions.
- Save-spacing installation: Better utilization of the piston stroke in tight installation space of the cylinder
- Favorable cost-benefit ratio.
- Fluid temperature (hydraulic oil) up to max. +95 °C.
- Compact dimensions: 10 mm installation space, 30 mm cushion zone.
Linear encoders DAX
- Low maintenance costs due to wear- and maintenance-free measurement principle.
- Absolute measurement without reference run.
- Intelligent condition monitoring enables predictive maintenance of machines.
- Resolution: up to 10 μm.
- Measuring lengths: 50 mm to 2,500 mm.
Incremental encoders DGS80
- Reduction of installation time thanks to the easy-to-mount clamping ring and the stator couplings.
- Compact, space-saving design facilitates installation in tight installation spaces.
- Pulse per revolution: Up to 8,192.
- Housing diameter: 81 mm, diameter of through hollow shaft: 30 mm or 42 mm.
- Enclosure rating: IP65
Absolute encoders AFS/AFM60 Ethernet
- Fully scalable for binary, non-binary, and non-integer resolutions thanks to round axis functionality.
- Compact and cost-efficient design.
- High-resolution absolute encoder with up to 30 bits (AFM60) or 18 bits (AFS60).
- Connection type: 3 x M12 axial plug.
- Status display via 5 LEDs.
Incremental encoders DUS60
- Universal power supply and a rotatable connector reduce the number of variants required and provide increased installation flexibility
- Anti-dither functionality maintains a high level of productivity also in high vibration applications
- Pulses per revolution: Up to 2,400
- Communication interfaces: TTL/HTL
- Connection types: M12 male connector or cable
