Flow sensors FFU

Distribution partners
Safe multibeam scanners ScanGrids2
- Safety level: Type 2, PL c, SIL1, SILCL1
- Warning field range: 4 m
- Scanning angle: 150°
- Resolution (can be configured): 50 mm, 70 mm, 150 mm, 200 mm
Distribution partners

Photoelectric sensors VTF18-4P1440 SICK 100 mm PNP

Sensor/ detection principle: Photoelectric proximity sensor, Background blanking; Sensing range Max: 3 mm ... 100 mm; Switching output: PNP- Light /Dark switching; Connection type: Connector M12, 4-pin
Distribution partners

Photoelectric sensors VTF18-4P1212 SICK 100 mm PNP

Sensor/ detection principle: Photoelectric proximity sensor, Background blanking; Sensing range Max: 3 mm ... 100 mm; Switching output: PNP- Light /Dark switching; Connection type: Cable, 4-wire, 2 m
Distribution partners
Absolute encoders AHS/AHM 36
- Encoder design: Singleturn / Multiturn
- Shaft type: Solid shaft, Servo flange/ Solid shaft, face mount flange/ Blind hollow shaft/ Shaft diameter
- Easy integration into various control environments with IO-Link, CANopen and SSI interfaces
- High resistance to ambient influences due to stainless steel design and IP69K enclosure rating (Inox versions)
- 36 mm absolute encoder with maximum 26 bits (singleturn: 14 bits multiturn: 12 bits)
- IP67 to IP69K protection class
Distribution partners
Pressure sensor PHT
- Device type: Pressure transmitter
- Measuring ranges
Gauge pressure: 0 bar ... 0.25 bar up to 0 bar ... 25 bar

Absolute pressure: 0 bar ... 0,25 bar up to 0 bar ... 16 bar

Compound pressure: –1 bar ... 0 bar up to –1 bar ... +15 bar
- Accuracy: ≤ ± 0.25 % of the span/ ≤ ± 0.5 % of the span
- Output signal: Analog
- Bi-color display (green/red) clearly shows the status of the output signal (within or outside the target range)
Distribution partners
Pressure sensors PAC50
- Device type: Pressure switch
- Measuring ranges: –1 bar ... 0 bar; –1 bar ... +1 bar; 0 bar ... +6 bar; 0 bar ... +10 bar; –1 bar ... 10 bar (Gauge pressure)
- Accuracy: ≤ ± 1.5 % of the span
- Output signal: Configurable switching outputs PNP, NPN or push-pull analog output signal plus optional IO-Link
- Bi-color display (green/red) clearly shows the status of the output signal (within or outside the target range)
- Measuring range for gauge pressure (vacuum and overpressure)
Distribution partners

Capacitive proximity CM18-08BPP-KC1 SICK 8 mm PNP

Thread size: M18 x 1; Sensing range: 3 mm ... 8 mm; Housing material: Plastic; Enclosure rating: IP67; Connection: Male connector M12, 4-pin
Distribution partners
Encoder EcoLine
- Measuring range: 0 m ... 10 m
- Resolution: 0.001 mm ... 0.14 mm
- Communication interface: IO-Link / IO-Link V1.1 / COM3 (230,4 kBaud)/ CANopen/ SSI/ PROFINET/ EtherCAT®/ EtherNet/IP™/ DeviceNet™/ PROFIBUS DP/ 4...20 mA/ 0...10 V/ Incremental / TTL / RS-422/ Incremental (HTL / Push pull)/ Incremental (TTL / HTL)
- Very small, slim housing (55 mm ... 190 mm) with spring integrated in the measurement drum
