The product Absolute encoders AFM60A-BBAA262144 is designed in accordance with European industrial standards, providing all essential technical specifications to help engineers easily select and integrate it into their systems. These specifications include measuring range/detection capability, accuracy, response time, output signal, power supply, IP protection rating, and operating environmental conditions.
Depending on the specific model and application, the device may support various connection options, communication protocols, or advanced features to meet the requirements of automation, safety, and reliability in industrial environments.
Below is the detailed technical specification table of the product:
| Safety-related parameters | |
| MTTFD (mean time to dangerous failure) | 250 years (EN ISO 13849-1) |
| Performance | |
| Number of steps per revolution (max. resolution) | 262,144 (18 bit) |
| Number of revolutions | 4,096 (12 bit) |
| Max. resolution (number of steps per revolution x number of revolutions) | 18 bit x 12 bit (262,144 x 4,096) |
| Error limits G | 0.03° |
| Repeatability standard deviation σr | 0.002° |
| Interfaces | |
| Communication interface | SSI |
| Initialization time | 50 ms |
| Position forming time | < 1 µs |
| Code type | Gray |
| Code sequence parameter adjustable | CW/CCW (V/R̅) parameter adjustable |
| Clock frequency | ≤ 2 MHz |
| Set (electronic adjustment) | H-active (L = 0 – 3 V, H = 4,0 – Us V) |
| CW/CCW (counting sequence when turning) | L-active (L = 0 – 1,5 V, H = 2,0 – Us V) |
| Electronics | |
| Connection type | Male connector, M23, 12-pin, radial |
| Supply voltage | 4.5 … 32 V |
| Power consumption | ≤ 0.7 W (without load) |
| Reverse polarity protection | ✔ |
| Mechanics | |
| Mechanical design | Blind hollow shaft |
| Shaft diameter | 8 mm |
| Characteristics of the shaft | Front clamp |
| Weight | 0.2 kg |
| Shaft material | Stainless steel |
| Flange material | Aluminum |
| Housing material | Aluminum die cast |
| Start up torque | < 0.8 Ncm (+20 °C) |
| Operating torque | < 0.6 Ncm (+20 °C) |
| Permissible movement static | ± 0.3 mm (radial) ± 0.5 mm (axial) |
| Permissible movement dynamic | ± 0.05 mm (radial) ± 0.1 mm (axial) |
| Operating speed | ≤ 6,000 min⁻¹ |
| Moment of inertia of the rotor | 40 gcm² |
| Bearing lifetime | 3.0 x 10^9 revolutions |
| Angular acceleration | ≤ 500,000 rad/s² |
| Ambient data | |
| EMC | According to EN 61000-6-2 and EN 61000-6-3 |
| Enclosure rating | IP65, shaft side (IEC 60529) IP67, housing side (IEC 60529) |
| Permissible relative humidity | 90 % (Condensation not permitted) |
| Operating temperature range | –40 °C … +100 °C |
| Storage temperature range | –40 °C … +100 °C, without package |
| Resistance to shocks | 60 g, 6 ms (EN 60068-2-27) |
| Resistance to vibration | 20 g, 10 Hz … 2,000 Hz (EN 60068-2-6) |
| Certificates | |
| EU declaration of conformity | ✔ |
| UK declaration of conformity | ✔ |
| ACMA declaration of conformity | ✔ |
| Moroccan declaration of conformity | ✔ |
| China RoHS | ✔ |
| cULus certificate | ✔ |
| Information according to Art. 3 of Data Act (Regulation EU 2023/2854) | ✔ |
| Classifications | |
| ECLASS 5.0 | 27270502 |
| ECLASS 5.1.4 | 27270502 |
| ECLASS 6.0 | 27270590 |
| ECLASS 6.2 | 27270590 |
| ECLASS 7.0 | 27270502 |
| ECLASS 8.0 | 27270502 |
| ECLASS 8.1 | 27270502 |
| ECLASS 9.0 | 27270502 |
| ECLASS 10.0 | 27270502 |
| ECLASS 11.0 | 27270502 |
| ECLASS 12.0 | 27270502 |
| ETIM 5.0 | EC001486 |
| ETIM 6.0 | EC001486 |
| ETIM 7.0 | EC001486 |
| ETIM 8.0 | EC001486 |
| UNSPSC 16.0901 | 41112113 |
