The product Incremental encoders DBS60E-R1FQD1024 is designed in accordance with European industrial standards, providing all essential technical specifications to help engineers easily select and integrate it into their systems. These specifications include measuring range/detection capability, accuracy, response time, output signal, power supply, IP protection rating, and operating environmental conditions.
Depending on the specific model and application, the device may support various connection options, communication protocols, or advanced features to meet the requirements of automation, safety, and reliability in industrial environments.
Below is the detailed technical specification table of the product:
| Safety-related parameters | |
| MTTFD (mean time to dangerous failure) | 500 years (EN ISO 13849-1) |
| Performance | |
| Pulses per revolution | 1,024 |
| Measuring step | ≤ 90°, electric/pulses per revolution |
| Measuring step deviation | ± 18° / pulses per revolution |
| Error limits | Measuring step deviation x 3 |
| Duty cycle | ≤ 0.5 ± 5 % |
| Interfaces | |
| Communication interface | Incremental |
| Communication Interface detail | TTL / HTL / HTL |
| Number of signal channels | 6-channel |
| Initialization time | < 5 ms |
| Output frequency | + 300 kHz |
| Load current | ≤ 30 mA, per channel |
| Power consumption | ≤ 0.5 W (without load) |
| Electronics | |
| Connection type | Cable, 8-wire, with male connector, M23, 12-pin, universal, 0.5 m |
| Supply voltage | 4.5 … 30 V |
| Reference signal, number | 1 |
| Reference signal, position | 90°, electric, logically gated with A and B |
| Reverse polarity protection | ✔ |
| Short-circuit protection of the outputs | ✔ |
| Mechanics | |
| Mechanical design | Through hollow shaft |
| Shaft diameter | 6 mm Rear clamping |
| Flange type / stator coupling | 1-sided stator coupling, slot, screw hole circle radius 31.5–48.5 mm |
| Weight | + 0.25 kg |
| Shaft material | Stainless steel with plastic shaft |
| Flange material | Aluminum |
| Housing material | Aluminum |
| Material, cable | PVC |
| Start up torque | + 0.5 Ncm (+20 °C) |
| Operating torque | 0.4 Ncm (+20 °C) |
| Permissible movement static | ± 0.3 mm (radial) ± 0.5 mm (axial) |
| Permissible movement dynamic | ± 0.1 mm (radial) ± 0.2 mm (axial) |
| Operating speed | 6,000 min⁻¹ |
| Maximum operating speed | 9,000 min⁻¹ |
| Moment of inertia of the rotor | 50 gcm² |
| Bearing lifetime | 3.6 x 10⁹ revolutions |
| Angular acceleration | ≤ 200,000 rad/s² |
| Ambient data | |
| EMC | According to EN 61000-6-2 and EN 61000-6-3 |
| Enclosure rating | IP65, housing side (IEC 60529) IP65, shaft side (IEC 60529) |
| Permissible relative humidity | 90 % (Condensation not permitted) |
| Operating temperature range | –30 °C … +100 °C, at maximum 3,000 pulses per revolution |
| Storage temperature range | –40 °C … +100 °C, without package |
| Resistance to shocks | 200 g, 3 ms (EN 60068-2-27) |
| Resistance to vibration | 30 g, 10 Hz … 2,000 Hz (EN 60068-2-6) |
| Classifications | |
| ECLASS 5.0 | 27270501 |
| ECLASS 5.1.4 | 27270501 |
| ECLASS 6.0 | 27270590 |
| ECLASS 6.2 | 27270590 |
| ECLASS 7.0 | 27270501 |
| ECLASS 8.0 | 27270501 |
| ECLASS 8.1 | 27270501 |
| ECLASS 9.0 | 27270501 |
| ECLASS 10.0 | 27270501 |
| ECLASS 11.0 | 27270501 |
| ECLASS 12.0 | 27270501 |
| ETIM 5.0 | EC001486 |
| ETIM 6.0 | EC001486 |
| ETIM 7.0 | EC001486 |
| ETIM 8.0 | EC001486 |
| UNSPSC 16.0901 | 41112113 |
