Part number:
| Product | Part no. | Communication interface | Target | Maximum required distance | Number of digital outputs | Light spot horizontal | Light spot vertical |
| DT1000-S11102 | 1075437 | Ethernet, PROFIBUS DP, Serial, SSI | natural objects | 155 m, 460 m | 2 | 5 mm, 20 mm, 35 mm, 150 mm, 290 mm, 570 mm | 20 mm, 25 mm, 50 mm, 80 mm, 140 mm |
| DL1000-S11102 | 1075439 | Ethernet, PROFIBUS DP, Serial, SSI | Reflector | 1500 m | 2 | 5 mm, 20 mm, 35 mm, 150 mm, 290 mm, 570 mm, 4200 mm | 20 mm, 25 mm, 50 mm, 80 mm, 140 mm, 920 mm |
| DT1000-S11112 | 1097425 | Ethernet, Serial, SSI, PROFINET | natural objects | 155 m, 460 m | 2 | 5 mm, 20 mm, 35 mm, 150 mm, 290 mm, 570 mm | 20 mm, 25 mm, 50 mm, 80 mm, 140 mm |
| DL1000-S11110 | 1100075 | Ethernet, Serial, SSI, EtherNet/IP™ | Reflector | 1500 m | 2 | 5 mm, 20 mm, 35 mm, 150 mm, 290 mm, 570 mm, 4200 mm | 20 mm, 25 mm, 50 mm, 80 mm, 140 mm, 920 mm |
| DT1000-S11110 | 1100074 | Ethernet, Serial, SSI, EtherNet/IP™ | natural objects | 155 m, 460 m | 2 | 5 mm, 20 mm, 35 mm, 150 mm, 290 mm, 570 mm | 20 mm, 25 mm, 50 mm, 80 mm, 140 mm |
| DT1000-S11101 | 1075436 | Ethernet, Serial, SSI | natural objects | 155 m, 460 m | 4 | 5 mm, 20 mm, 35 mm, 150 mm, 290 mm, 570 mm | 20 mm, 25 mm, 50 mm, 80 mm, 140 mm |
| DL1000-S11101 | 1075438 | Ethernet, Serial, SSI | Reflector | 1500 m | 4 | 5 mm, 20 mm, 35 mm, 150 mm, 290 mm, 4200 mm | 20 mm, 25 mm, 50 mm, 80 mm, 920 mm |
| DL1000-S11112 | 1099756 | Ethernet, Serial, SSI, PROFINET | Reflector | 1500 m | 2 | 5 mm, 20 mm, 35 mm, 150 mm, 290 mm, 570 mm, 4200 mm | 20 mm, 25 mm, 50 mm, 80 mm, 140 mm, 920 mm |
