Features:
- Sensor principle: Photoelectric retro-reflective sensor
- Dimensions (W x H x D): 90 mm x 50 mm x 90 mm
- Maximum range: 2m
- Operating range: 2m x 2m
- Minimum range: ≥ 0.4 m
- Minimum detectable object (MDO): 6 mm … 18 mm
- Response time: ≤ 20 ms
- Enclosure rating: IP54
Mechanics/ Electronics:
- Power supply: DC ≥ 24 V
- Switching output: 2 x PNP
- Connection type: Cable with plug M12, 8-pin, 390 mm
- Housing material: Aluminum
- Temperature range: –25 °C to +55 °C
