The product Connectors and cables STL-1204-G10ME90 is designed in accordance with European industrial standards, providing all essential technical specifications to help engineers easily select and integrate it into their systems. These specifications include measuring range/detection capability, accuracy, response time, output signal, power supply, IP protection rating, and operating environmental conditions.
Depending on the specific model and application, the device may support various connection options, communication protocols, or advanced features to meet the requirements of automation, safety, and reliability in industrial environments.
Below is the detailed technical specification table of the product:
| Technical specifications | |
| Connection type head A | Male connector, M12, 4-pin, straight, D-coded |
| Connection type head B | Flying leads |
| Locking nut material | Zinc die-cast, nickel-plated |
| Cable | 10 m, 4-wire, CAT5, CAT5e, PUR, halogen-free |
| Jacket material | PUR, halogen-free |
| Jacket color | Water blue (RAL 5021) |
| Cable diameter | 6.4 mm |
| Conductor cross section | 2 x 2 x 0.14 mm² |
| Shielding | Shielded |
| Flexible use | > 8 x cable diameter |
| Stationary position | > 4 x cable diameter |
| Signal type | Ethernet |
| Transmission characteristics | CAT5 |
| Data transmission rate | ≤ 100 Mbit/s |
| Enclosure rating | IP65/ IP67 |
| Stationary position | –20 °C … +80 °C |
| Certificates | |
| EU declaration of conformity | ✔ |
| China RoHS | ✔ |
| Classifications | |
| ECLASS 5.0 | 19030312 |
| ECLASS 5.1.4 | 19030312 |
| ECLASS 6.0 | 27060304 |
| ECLASS 6.2 | 27060304 |
| ECLASS 7.0 | 27060304 |
| ECLASS 8.0 | 27060304 |
| ECLASS 8.1 | 27060304 |
| ECLASS 9.0 | 27060304 |
| ECLASS 10.0 | 27060304 |
| ECLASS 11.0 | 27060304 |
| ECLASS 12.0 | 27060304 |
| ETIM 5.0 | EC000830 |
| ETIM 6.0 | EC000830 |
| ETIM 7.0 | EC003249 |
| ETIM 8.0 | EC003249 |
| UNSPSC 16.0901 | 26121604 |
