The product Laser distance sensors WTT2SLC-2P3092B03 is designed in accordance with European industrial standards, providing all essential technical specifications to help engineers easily select and integrate it into their systems. These specifications include measuring range/detection capability, accuracy, response time, output signal, power supply, IP protection rating, and operating environmental conditions.
Depending on the specific model and application, the device may support various connection options, communication protocols, or advanced features to meet the requirements of automation, safety, and reliability in industrial environments.
Below is the detailed technical specification table of the product:
| Features | |
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Background suppression, Optical time-of-flight, distance value |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 50 mm … 800 mm |
| Sensing range | 50 mm … 800 mm |
| Repeatability | 2 mm … 5 mm |
| Accuracy | ± 20 mm |
| Type of light | Infrared light |
| Light source | Laser |
| Light spot size (distance) | Ø 10 mm (300 mm) |
| Wave length | 940 nm |
| Laser class | 1 |
| Adjustment | Single teach-in button, IO-Link |
| Special applications | Detecting small objects |
| MTTFD | 925 years |
| DCavg | 0 % |
| Interfaces | |
| Communication interface | IO-Link V1.1 |
| Communication Interface detail | COM2 (38,4 kBaud) |
| Cycle time | 5 ms |
| Process data length | 4 Byte |
| Process data structure | Bit 0 = switching signal QL₁ Bit 1 = switching signal QL₂ Bit 2 = detection signal Qint.1 Bit 3 = detection signal Qint.2 Bit 4 … 15 = empty Bit 16 … 31 = distance value |
| VendorID | 26 |
| DeviceID HEX | 0x8001B8 |
| DeviceID DEC | 8389048 |
| Electronics | |
| Supply voltage UB | 10 V DC … 30 V DC |
| Ripple | < 5 Vpp |
| Current consumption | 20 mA |
| Switching output | PNP |
| Switching mode | Light/dark switching |
| Output current Imax. | ≤ 50 mA |
| Response time | Typ. 95 ms |
| Switching frequency | 5 Hz |
| Analog output | – |
| Circuit protection | A B D |
| Protection class | III |
| Enclosure rating | IP67 |
| Mechanics | |
| Dimensions (W x H x D) | 7.7 mm x 27.5 mm x 13.5 mm |
| Housing material | Plastic, MABS ABS |
| Optics material | Plastic, PMMA |
| Connection type | Cable with JST-connector, 300 mm |
| Cable diameter | Ø 3 mm |
| Cable material | Plastic, PVC |
| Ambient data | |
| Ambient operating temperature | –25 °C … +50 °C |
| Ambient temperature, storage | –40 °C … +75 °C |
| Smart Task | |
| Smart Task name | Base logics |
| Logic function | Direct AND OR WINDOW Hysteresis |
| Timer function | Deactivated Switch-on delay Off delay ON and OFF delay Impulse (one shot) |
| Inverter | Yes |
| Switching frequency | SIO Direct: 5 Hz SIO Logic: 5 Hz IOL: 5 Hz |
| Response time | SIO Direct: typ. 90 ms SIO Logic: typ. 90 ms IOL: typ. 95 ms |
| Certificates | |
| EU declaration of conformity | ✔ |
| UK declaration of conformity | ✔ |
| ACMA declaration of conformity | ✔ |
| Moroccan declaration of conformity | ✔ |
| China RoHS | ✔ |
| cULus certificate | ✔ |
| IO-Link certificate | ✔ |
| Laser safety (IEC 60825-1) certificate | ✔ |
| Information according to Art. 3 of Data Act (Regulation EU 2023/2854) | ✔ |
| Classifications | |
| ECLASS 5.1.4 | 27270903 |
| ECLASS 6.0 | 27270903 |
| ECLASS 7.0 | 27270903 |
| ECLASS 8.0 | 27270903 |
| ECLASS 9.0 | 27270903 |
| ECLASS 10.0 | 27270903 |
| ECLASS 11.0 | 27270903 |
| ECLASS 12.0 | 27270903 |
| ECLASS 13.0 | 27270903 |
| ECLASS 14.0 | 27270903 |
| ECLASS 15.0 | 27270903 |
| ETIM 6.0 | EC002719 |
| ETIM 7.0 | EC002719 |
| ETIM 8.0 | EC002719 |
| ETIM 9.0 | EC002719 |
| ETIM 10.0 | EC002719 |
| UNSPSC 091201.0 | 39121528 |
| UNSPSC 100501.0 | 39121528 |
| UNSPSC 111201.0 | 39121528 |
| UNSPSC 120901.0 | 39121528 |
| UNSPSC 131201.0 | 39121528 |
| UNSPSC 140801.0 | 39121528 |
| UNSPSC 151101.0 | 39121528 |
| UNSPSC 160901.0 | 39121528 |
| UNSPSC 171001.0 | 39121528 |
| UNSPSC 180801.0 | 39121528 |
| UNSPSC 190501.0 | 39121528 |
| UNSPSC 200601.0 | 39121528 |
| UNSPSC 210901.0 | 39121528 |
| UNSPSC 220601.0 | 39121528 |
| UNSPSC 230701.0 | 39121528 |
| UNSPSC 240301.0 | 39121528 |
| UNSPSC 250901.0 | 39121528 |
| UNSPSC 260801.0 | 39121528 |
