The product Power supply units and power supply cables Power supply unit is designed in accordance with European industrial standards, providing all essential technical specifications to help engineers easily select and integrate it into their systems. These specifications include measuring range/detection capability, accuracy, response time, output signal, power supply, IP protection rating, and operating environmental conditions.
Depending on the specific model and application, the device may support various connection options, communication protocols, or advanced features to meet the requirements of automation, safety, and reliability in industrial environments.
Below is the detailed technical specification table of the product:
| Features | |
| Product segment | Power supply units and power supply cables |
| Product | Power supply units |
| Description | 24 V power supply unit with assembled M12 socket, 5-pin, A-coded. Including plug for Europe, USA, England, Australia |
| Electronics | |
| Input voltage | 100 V AC … 240 V AC |
| Output voltage | 24 V DC |
| Maximum output current | ≤ 1 A |
| Mechanics | |
| Length of cable | 1.5 m |
| Dimensions (L x W x H) | 93 mm x 46 mm x 36 mm (Basic module, without male connector) |
| Ambient data | |
| Ambient operating temperature | 0 °C … +40 °C |
| Classifications | |
| ECLASS 5.0 | 27040301 |
| ECLASS 5.1.4 | 27040301 |
| ECLASS 6.0 | 27242611 |
| ECLASS 6.2 | 27242611 |
| ECLASS 7.0 | 27040301 |
| ECLASS 8.0 | 27040301 |
| ECLASS 8.1 | 27040301 |
| ECLASS 9.0 | 27040301 |
| ECLASS 10.0 | 27040301 |
| ECLASS 11.0 | 27040301 |
| ECLASS 12.0 | 27040301 |
| ETIM 5.0 | EC002542 |
| ETIM 6.0 | EC002542 |
| ETIM 7.0 | EC002542 |
| ETIM 8.0 | EC002542 |
| UNSPSC 16.0901 | 39121004 |
