The product Connectors and cables SMEMA N+1 male connection cable is designed in accordance with European industrial standards, providing all essential technical specifications to help engineers easily select and integrate it into their systems. These specifications include measuring range/detection capability, accuracy, response time, output signal, power supply, IP protection rating, and operating environmental conditions.
Depending on the specific model and application, the device may support various connection options, communication protocols, or advanced features to meet the requirements of automation, safety, and reliability in industrial environments.
Below is the detailed technical specification table of the product:
| Technical specifications | |
| Connection type head A | Male connector, M12, 4-pin, A-coded |
| Connection type head B | Male connector, SMEMA CPC, 14-pin |
| Locking plug connector | Screw connection |
| Connector material | TPU (head A) |
| Connector color | Black |
| Cable | 2 m, 4-wire, PUR, halogen-free |
| Jacket material | PUR, halogen-free |
| Jacket color | Black |
| Cable diameter | 4.5 mm |
| Conductor cross section | 0.34 mm² |
| Shielding | Unshielded |
| Flexible use | > 10 x cable diameter |
| Stationary position | > 5 x cable diameter |
| Drag chain operation | > 10 x cable diameter |
| Bending cycles | 10,000,000 |
| Current loading | 4 A |
| Signal type | Digital I/Os |
| Flexible use | –25 °C … +80 °C |
| Stationary position | –40 °C … +80 °C |
| Drag chain operation | –25 °C … +80 °C |
| Head | –25 °C … +85 °C |
| Certificates | |
| EU declaration of conformity | ✔ |
| UK declaration of conformity | ✔ |
| China RoHS | ✔ |
