The product Connectors and cables YM2A6B-020UD3XLEAX is designed in accordance with European industrial standards, providing all essential technical specifications to help engineers easily select and integrate it into their systems. These specifications include measuring range/detection capability, accuracy, response time, output signal, power supply, IP protection rating, and operating environmental conditions.
Depending on the specific model and application, the device may support various connection options, communication protocols, or advanced features to meet the requirements of automation, safety, and reliability in industrial environments.
Below is the detailed technical specification table of the product:
| Technical specifications | |
| Connection type head A | Male connector, M12, 12-pin, straight, A-coded |
| Connection type head B | Flying leads |
| Locking plug connector | Screw connection |
| Connector material | TPU |
| Connector color | Black |
| Locking nut material | Stainless steel (V4A/1.4404) |
| Locking nut material A | Stainless steel (V4A/1.4404) |
| Tightening torque | 0.6 Nm |
| Width across flats | 13 |
| Cable | 2 m, 12-wire, PUR, halogen-free |
| Jacket material | PUR, halogen-free |
| Jacket color | Black |
| Cable diameter | 7.2 mm |
| Conductor cross section | 2 x 2 x 0.14 mm² |
| Shielding | Shielded |
| Flexible use | > 10 x cable diameter |
| Stationary position | > 5 x cable diameter |
| Drag chain operation | > 10 x cable diameter |
| Bending cycles | 5,000,000 |
| Rated impulse voltage | 0.8 kV |
| Current loading | 1.5 A |
| Traversing speed | 3.3 m/s |
| Travelling distance | 5 m |
| Acceleration | ≤ 5 m/s² |
| Signal type | Sensor/actuator cable |
| Torsion force | 1 m |
| Torsion cycles | 500,000 |
| Cycles per minutes | 35 |
| Application | Drag chain operation Zones with oils and lubricants Robot Outdoor |
| Enclosure rating | IP65 / IP66K / IP67 |
| Flexible use | –25 °C … +80 °C |
| Stationary position | –40 °C … +80 °C |
| Drag chain operation | –25 °C … +80 °C |
| Head | –25 °C … +85 °C |
| Contamination rating | 3 |
| Overvoltage category | III |
| Certificates | |
| EU declaration of conformity | ✔ |
| China RoHS | ✔ |
| cULus certificate | ✔ |
| Classifications | |
| ECLASS 5.1.4 | 27269202 |
| ECLASS 6.0 | 27269202 |
| ECLASS 7.0 | 27449203 |
| ECLASS 8.0 | 27449203 |
| ECLASS 9.0 | 27440392 |
| ECLASS 10.0 | 27440392 |
| ECLASS 11.0 | 27440392 |
| ECLASS 12.0 | 27440392 |
| ECLASS 13.0 | 27440392 |
| ECLASS 14.0 | 27440392 |
| ECLASS 15.0 | 27440392 |
| ETIM 6.0 | EC000830 |
| ETIM 7.0 | EC003249 |
| ETIM 8.0 | EC003249 |
| ETIM 9.0 | EC003249 |
| ETIM 10.0 | EC003249 |
| UNSPSC 091201.0 | 26121604 |
| UNSPSC 100501.0 | 26121604 |
| UNSPSC 111201.0 | 26121604 |
| UNSPSC 120901.0 | 26121604 |
| UNSPSC 131201.0 | 26121604 |
| UNSPSC 140801.0 | 26121604 |
| UNSPSC 151101.0 | 26121604 |
| UNSPSC 160901.0 | 26121604 |
| UNSPSC 171001.0 | 26121604 |
| UNSPSC 180801.0 | 26121604 |
| UNSPSC 190501.0 | 26121604 |
| UNSPSC 200601.0 | 26121604 |
| UNSPSC 210901.0 | 26121604 |
| UNSPSC 220601.0 | 26121604 |
| UNSPSC 230701.0 | 26121604 |
| UNSPSC 240301.0 | 26121604 |
| UNSPSC 250901.0 | 26121604 |
| UNSPSC 260801.0 | 26121604 |
