Safety laser scanners S300 Mini

  • Easy integration due to compact design.
  • 270° scanning angle allows allround protection using only two scanners.
  • Up to 3 m protective field range.
  • EFI interface for safe SICK device communication.
Categories: , , Tags: , , , , ,

Part number:

Product Part no.: Sub product family Application Protective field range Number of fields Scanning angle Integration in the control system Incremental encoder inputs Number of monitoring cases Connection type Safety level
S32B-3011BA 1056430 S300 Mini Standard Indoor 3 m 3 270° Local inputs and outputs (I/O) No 1 M12 PL d, SIL 2, Type 3
S32B-3011EA 1056431 S300 Mini Remote Indoor 3 m 48 270° EFI Yes 32 M12 PL d, SIL 2, Type 3
S32B-2011BA 1050932 S300 Mini Standard Indoor 2 m 3 270° Local inputs and outputs (I/O) No 1 M12 PL d, SIL 2, Type 3
S32B-2011EA 1051884 S300 Mini Remote Indoor 2 m 48 270° EFI Yes 32 M12 PL d, SIL 2, Type 3
S32B-0011BA 1058000 S300 Mini Standard Indoor 1 m 3 270° Local inputs and outputs (I/O) No 1 M12 PL d, SIL 2, Type 3

At a glance:

  • Successfully in use for more than 10 years.
  • Easy integration due to compact design.
  • 270° scanning angle allows allround protection using only two scanners.
  • Safe device communication for easy integration of safety laser scanners and low cabling requirements.

Features:

  • Compact design.
  • Up to 3 m protective field range.
  • 270° scanning angle.
  • Up to 48 freely configurable fields and 16 switchable field sets.
  • Configuration using the CDS software.
  • EFI interface for safe SICK device communication.
